ODROID-C1+ (Hardkernel) - quad core 1.5 GHz + 1 GB RAM

This version is a revised version of the proposed in December 2014 ODROID-C1. Hard Kernel made the following changes:

  • Instead Micro HDMI is now used and CEC should now also work.
  • The power supply can now be done via the USB OTG port.
  • MicroSD card slot more accessible.
  • The width of the heatsink is smaller and now included.
  • The baseplate is blue now.

Pro vs. Contra

  • proGigabit Network

  • proTwo storage media slots Micro SD & eMMC

  • contraNo dual screen HDMI / GPIO possible

Info

Producer: Hardkernel kr

http://www.hardkernel.com

Status: End of Life

Price: 44 €

Technical Specifications - Released: 21.07.2015

SOC: Amlogic S805

CPU Architecture: ARM Cortex-A4

CPU Cores: 4

CPU Frequency: 1.5 GHz

GPU: 2 x ARM Mali-450
MP2 GPU @ 600MHz
-

RAM: 1 GB

RAM Type: DDR3

RAM Speed: 792 MHz

Video output: HDMI 1.4

HDMI CEC: Yes

Audio output: HDMI

USB: 4 x USB 2.0

USB OTG: 1 x

Ethernet: 10/100/1000 MBit/s

Wifi: -

Bluetooth: -

GPIO: 40 Pin

Storage: MicroSD, eMMC

Power: 2A @ 5V - 2.5x0.8mm

Power idle: -

Power max: -

Dimension: 86.6 x 56.7 x 20.8 mm

Weight: 54 g

Operatingsystem: Ubuntu 14.04 LTS
